IN175

Rugged Laptop

The Ultimate Powerful,
Expandable Rugged Mobile Workstation

The IN175 Fully Rugged Laptop is a professional-grade mobile workstation engineered for demanding industrial field and outdoor applications. Combining powerful computing, professional graphics, and a 17.3-inch display, it handles complex workloads stably and efficiently. Equipped with an 800-nit high-brightness optically bonded sunlight-readable display for clear visibility in strong light, optional touchscreen supports operation in rain, low temperatures and with gloves. Its hot-swappable dual-battery system provides all-day power; the lightweight magnesium-aluminum chassis balances durability and portability, with IP66 dust/water resistance, wide-temperature stability, and resistance to drops, vibrations and corrosion. It also features rich professional interfaces, stable wireless connectivity, modular expansion and hardware-level security, flexibly adapting to mission-critical scenarios and supporting field professionals in harsh conditions.

High-Performance Computing

Powered by 10th Gen Intel® Core™ i7 processors and optional NVIDIA® GeForce® RTX 4060 8GB graphics, the IN175 delivers consistent and powerful performance for compute-intensive and graphics-demanding industrial applications. With up to 128GB DDR4 memory and high-speed PCIe Gen4 storage, it enables efficient multitasking and fast data processing, ensuring smooth operation of large professional software in field environments.

Stunning 17.3-inch Outdoor Visuals

The 17.3-inch FHD (1920×1080) high-brightness optically bonded sunlight-readable display features 800 nits peak brightness, delivering crystal-clear visibility even under direct outdoor sunlight while effectively eliminating glare and reflections. The optional capacitive multi-touch screen supports glove-friendly operation, and its rugged reinforced panel provides excellent scratch and shock resistance, keeping the screen visible and responsive in all outdoor working conditions

Superb Connectivity

The IN175 is equipped with a full suite of rugged-optimized interfaces, including USB Type-C, multiple USB ports, dual LAN, HDMI, and optional serial interfaces, ensuring seamless connectivity even in remote field locations. Integrated Intel® Wi-Fi 6, Bluetooth v5.2, and GNSS (GPS/GLONASS/Galileo) ensure reliable communication and positioning, while hardware-level security features help protect system access and data transmission.

Comprehensive Data Security

The IN175 offers a comprehensive suite of security features designed to protect both system access and critical industrial data. Authentication is supported through multi-factor mechanisms, including a fingerprint reader, smart card reader, and optional Windows Hello camera for secure and efficient identity verification.

For data protection, the IN175 provides flexible storage configurations, optional dual drives, and secure data handling capabilities, ensuring that sensitive information remains safeguarded throughout operation. These features make the IN175 well-suited for the data security requirements of mission-critical industries such as defense, aerospace, and industrial automation.

Built For All-Day Mobility

Designed for uninterrupted field operations, the IN175 features a hot-swappable dual-battery system. A 155Wh main battery (with an optional 184.3Wh low-temperature version) combined with a 13Wh auxiliary battery delivers stable, all-day power for sustained productivity during extended use. Its lightweight magnesium-aluminum alloy chassis balances durability and portability, making it well-suited for mobile field applications such as on-site exploration, emergency rescue, and industrial inspection.

Comprehensive Ruggedization for Extreme Environments

Engineered for exceptional performance in harsh environments, the IN175 meets MIL-STD-810H and MIL-STD-461G certification standards and is IP66 rated for dust and water resistance. It withstands extreme temperatures, drops, vibrations, and corrosion, making it a trusted companion in industrial fieldwork, outdoor exploration, and emergency response scenarios.

Unlock the Power of Customization with IN175

The IN175’s innovative "Infinite Expansion" modular design offers unparalleled customization, meeting the unique needs of various industries and applications. From expanding storage to adding connectivity options, users can configure the IN175 with up to 8TB of total storage (2×NVMe SSD + 2×2.5-inch SATA SSD), dual drives, and optional 5G connectivity or additional serial interfaces.
Whether you need enhanced graphics for professional industrial design or specific industry modules, the IN175 provides flexible solutions that adapt easily through docking stations and other peripherals. Its rugged design ensures it can handle any task, whether it’s field operations or data processing in remote environments. With powerful performance, flexibility, and robust data security, the IN175 is built to excel in mission-critical environments.

IN175 Specifications

Download PDF

CPU

Intel® Core ™ i7-10750H Processor (12M Cache , up to 5.00 GHz) FC-BGA14F ,
Tray Processor Base Frequency 2.60 GHz

Graphics Controller

Intel® UHD Graphics for 10th Gen Intel® Processors
Optional:NVIDIA GeForce RTX3060M 12G/6G
Optional:NVIDIA GeForce RTX4060 8G

Memory

RAM 16 GB (SO-DIMM*2)
Optional: 8 GB /16 G/32G/64G/128 G (Max)

Storage*4

SSD1: 1TB , optional 128 GB/256GB/2TB NVMe
SSD2: 1TB , optional 128 GB/256GB/2TB NVMe
(optional GPS module)
Storage 3/4: 2.5-inch SATA SSD ,
128 GB/256GB/1TB/4TB ×2

Display

17.3 inch ,1920 (RGB)*1080 ,Luminance 800cd/㎡

Keyboard

Waterproof LED backlit membrane keyboard with FN shortcut functions

Communication

1000M Ethernet
Intel® Wi-Fi 6 802.11ax（removable）
Bluetooth (v5.2)（removable）
4G LTE mobile broadband（removable）
standard precision GNSS(GPS、GLONASS、Galileo)

I/OInterfaces

USB 3.0 Gen2*4
RJ45 (10/100/1000Mbps) *2
DB2（RS232xRS422x485）*1（choose by BIOS）
DB1（RS232）*1
HDMI*1
Power aviation plug R5.5*1
SIM Card *1
3.5 mm headphone/microphone jack*1

Environmental Specification

Temperature:
- Operating: -20ºC to 55ºC (Customizable：-40ºC to 55ºC)
- Storage: -40ºC to 70ºC (Customizable：-50ºC to 70ºC)
Humidity:5%- 95% RH , non-condensing

Battery

Main battery capacity：155Wh ,（pluggable）option：183W（work -40℃）
Auxiliary battery capacity：13Wh（non-removable）

Adapter

Input voltage: AC100V ~240V , 60/50Hz , Output voltage: DC19V 9.47A/188W EU
